FRP Ladder Tray

Name: FRP Ladder Tray
Brand: OM ENTERPRISES

Get a Price/Quote

MOQ : 1 Meter

FRP Ladder Tray Specification

Max. Working Load
Up to 150 Kg/m, depending on size and design

Conductor Material
Non-conductive (FRP material)

Deflection
7 mm at max load (as per test standards)

Surface Finish
Smooth, Corrosion Resistant

Product Type
Ladder Type Cable Tray

Material
FRP (Fiberglass Reinforced Plastic)

Standard Thickness
3 mm / 5 mm / 6 mm

Length
2.5 Meter / 3 Meter

Width
150 mm to 1200 mm

Side Rail Height
50 mm to 150 mm

Weight
Lightweight, varies as per size (typically 3-8 kg/m)

Dimension (L*W*H)
Customizable as per requirements

Color
Yellow / Grey / Custom on Request

Standard Compliances
IS: 6746, ASTM D635, NEMA FG-1

Accessories
Bends, Tees, Crosses, Reducers, Couplers available

Temperature Range
-40°C to +120°C

Fire Retardant Rating
Class 1 as per ASTM D635

Installation Type
Indoor/Outdoor

UV Resistance
Excellent

Applications
Used for cable management in industrial, marine, chemical, and utility installations

Chemical Resistance
High resistance to acids, alkalis, and solvents

Dielectric Strength
>18 KV/mm

Rung Spacing
250 mm (center to center)

FRP Ladder Tray Trade Information

Minimum Order Quantity
1 Meter

Supply Ability
1000 Meters Per Day

Delivery Time
3-5 Days

About FRP Ladder Tray

Om Enterprises is a big name which deals in the supplying and trading of premium quality FRP Ladder Tray which is used in various buildings for the construction of wire safety channels. Its unique ladder like design gives higher strength and sturdiness to resist large impact forces and harsh constructional conditions that ultimately leads to longer service life. Best in class fiber reinforced plastic is used for the fabrication of this FRP Ladder Tray which imparts greater strength and sturdiness.

Superior Fire Retardant and Chemical Resistance

Certified to Class 1 fire retardancy per ASTM D635 and compliant with IS:6746 and NEMA FG-1, the FRP ladder tray offers exceptional protection in hazardous environments. Its high resistance to acids, alkalis, and solvents ensures reliable performance even in chemically aggressive and high-temperature settings ranging from -40C to +120C.

Customizable and Versatile Design

Available in multiple lengths, widths, and side rail heights, this ladder tray can be tailored to meet specific installation requirements. Accessories such as bends, tees, and reducers allow for versatile configurations, making it perfect for cable management in industrial, marine, chemical, and utility facilities.

Safe and Efficient Cable Management

With excellent dielectric strength (>18 KV/mm) and non-conductive FRP material, the tray ensures safe separation of electrical cables. Its smooth, corrosion-resistant surface provides long-lasting performance, while its lightweight construction offers easy handling and installation in various environments.

FAQ's of FRP Ladder Tray:

Q: How is the FRP Ladder Tray installed?

A: The FRP Ladder Tray can be installed both indoors and outdoors using accessories like bends, tees, crosses, reducers, and couplers. It is mounted on supporting structures with proper brackets, ensuring stable placement and secure cable management.

Q: What makes the FRP Ladder Tray suitable for harsh environments?

A: Its high resistance to acids, alkalis, and solvents, combined with corrosion and UV resistance, ensures durability and performance in industrial, marine, and chemical installations, even under extreme conditions from -40C to +120C.

Q: When should I choose an FRP Ladder Tray over a metal tray?

A: Choose FRP Ladder Trays when non-conductive, lightweight, fire-retardant, and corrosion-resistant solutions are needed, especially in environments exposed to chemicals, moisture, and electrical hazards.

Q: Where can FRP Ladder Trays be used?

A: FRP Ladder Trays are ideal for cable management in industrial plants, marine facilities, chemical processing areas, utility installations, and any application requiring robust environmental and electrical protection.

Q: What is the process for customizing tray dimensions?

A: Tray dimensions such as length, width, thickness, and side rail height can be customized by specifying requirements to your supplier or manufacturer, ensuring a precise fit for your project's needs.

Q: How does the fire retardant rating benefit cable safety?

A: With a Class 1 fire retardancy rating per ASTM D635, the tray minimizes fire risks, providing added safety and compliance in installations where fire protection is crucial.

Q: What is the maximum working load, and how does it impact usage?

A: The tray can support up to 150 Kg/m, depending on its size and design. This makes it suitable for carrying large volumes of cables without excessive deflection, maintaining safety and structural integrity.
